Main characteristics
- Different activation modes: Plug & Play, RFID, key, APP etc
- Power: 3,6 – 7,2 – 11 – 22kW (AC)
- Connection options: B (socket) or C (plug)
- Customizable front cover
Enclosure able to include modular electrical protections following regulations REBT(ITC-BT-52) or customer needs
- MCCB
- RCCB type "A"
-Under and overvoltage protections
- Power sensor system: EV dynamic power charging balance following the main system consumption (home)
(Useful to avoid to contract upper power contracts to the Utility. Also to avoid ungodly power cuts made by the Utility power meter due to power overtakes)
- Optional Residual Current Monitor (RCM)
- Optional power rearmament, the VE charging station is able to rearm itself if the Utility power meter switches off
Mechanical characteristics
- High-strength polycarbonate (PC) enclosure
- V0 additive (flame retardant) + UV (ultraviolet protection)
- IP54 / IK08
